Name: Transmission OverHead Line

Display Field: CIRCUITNAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Transmission overhead lines do not include insulation, and is suitable for being run overhead.

Service Item Id: b1278c1ac77c409d804504029bf9f7ab

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 158001.02885242598
YMin: 308940.682841849
XMax: 238543.648278676
YMax: 484447.159584101
Spatial Reference: 2932  (2932)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SUBTYPECD
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Default Label:
UniqueValueInfos:
• Value: 1
  Label: HV Overhead Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [250, 252, 212, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SUBTYPECD

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: ObjectID )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• SUBTYPECD ( type: esriFieldTypeInteger, alias: SubtypeCD )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 6 , Coded Values: [CU: Copper] , [ACSR: ACSR] , [ACSRD: ACSR DOVE] , ...6 more... )
• VOLTAGE ( type: esriFieldTypeInteger, alias: Voltage , Coded Values: [66: 66 KV] , [132: 132 KV] , [220: 220 KV] , ...3 more... )
• PHASEDESIGNATION ( type: esriFieldTypeInteger, alias: Phase Designation , Coded Values: [4: R] , [2: Y] , [1: B] , ...4 more... )
• INSTALLATIONDATE ( type: esriFieldTypeDate, alias: Installation Date, length: 8 )
• CIRCUITNAME ( type: esriFieldTypeString, alias: Circuit Name, length: 30 )
• CIRCUITNUMBER ( type: esriFieldTypeString, alias: Circuit Number, length: 64 , Coded Values: [F1: F1] , [F2: F2] , [F3: F3] , ...18 more... )
• CONNECTIONSOURCE ( type: esriFieldTypeString, alias: Connection Source, length: 100 )
• CONNECTIONDESTINATION ( type: esriFieldTypeString, alias: Connection Destination, length: 100 )
• MEASUREDLENGTH ( type: esriFieldTypeDouble, alias: Measured Length , Range: [1, 10000] )
• TENSION ( type: esriFieldTypeString, alias: Tension, length: 20 )
• CCODEF1 ( type: esriFieldTypeString, alias: CCODEF1, length: 20 )
• CCODEF2 ( type: esriFieldTypeString, alias: CCODEF2, length: 20 )
• CONDUCTORSIZE ( type: esriFieldTypeInteger, alias: Conductor Size , Coded Values: [100: 100 mm2] , [150: 150 mm2] , [200: 200 mm2] , ...7 more... )
• INSULATIONMATERIAL ( type: esriFieldTypeString, alias: Insulation Material, length: 50 , Coded Values: [XLPE: XLPE] , [PILC: PILC] , [FIB: Fiber] , ...10 more... )
• EARTHWIRETYPE ( type: esriFieldTypeString, alias: Earthwire Type, length: 6 , Coded Values: [LYNX: LYNX] , [WOLF: WOLF] , [OPGW: OPGW] , ...3 more... )
• DATASOURCE ( type: esriFieldTypeString, alias: Data Source, length: 4 , Coded Values: [CAD: CADImport] , [GDB: GeoDatabase] , [SHP: ShapeFiles] , ...7 more... )
• CONFIDENCE ( type: esriFieldTypeInteger, alias: Confidence )
• RELIABLE ( type: esriFieldTypeInteger, alias: Reliable )
• GFCODE ( type: esriFieldTypeString, alias: GFCode, length: 20 )
• STATUSINDICATOR ( type: esriFieldTypeInteger, alias: Status Indicator , Coded Values: [0: None] , [1: Install] , [2: Remove] , ...7 more... )
• REMARKS ( type: esriFieldTypeString, alias: Remarks, length: 255 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Types:

ID: 1
Name: HV Overhead Line
Domains:
• ENABLED:
  Inherited
• MATERIAL:
  Inherited
• VOLTAGE:
  Inherited
• PHASEDESIGNATION:
  Inherited
• CIRCUITNUMBER:
  Inherited
• MEASUREDLENGTH:
  Inherited
• CONDUCTORSIZE:
  Inherited
• INSULATIONMATERIAL:
  Inherited
• EARTHWIRETYPE:
  Inherited
• DATASOURCE:
  Inherited
• STATUSINDICATOR:
  Inherited

---
